Double Side Polished Single Crystal 4H-N Sic Wafer

Ask Lasest Price
Brand Name :	ZMKJ
Model Number :	seed wafers
Price :	by case
Payment Terms :	T/T, Western Union, MoneyGram
Supply Ability :	1-50pcs/month
Delivery Time :	1-6weeks

Add to Cart

Product Details
Company Profile

Double Side Polished Single Crystal 4H-N Sic Wafer

2inch/3inch/4inch/6inch 6H-N/4H-SEMI/ 4H-N SIC ingots/4inch 6inch silicon carbide SIC 4H-N seed crystal Wafer For crystal growth

About Silicon Carbide (SiC)Crystal

Silicon carbide (SiC), also known as carborundum, is a semiconductor containing silicon and carbon with chemical formula SiC. SiC is used in semiconductor electronics devices that operate at high temperatures or high voltages, or both.SiC is also one of the important LED components, it is a popular substrate for growing GaN devices, and it also serves as a heat spreader in high-power LEDs.

1. Description

Property	4H-SiC, Single Crystal	6H-SiC, Single Crystal
Lattice Parameters	a=3.076 Å c=10.053 Å	a=3.073 Å c=15.117 Å
Stacking Sequence	ABCB	ABCACB
Mohs Hardness	≈9.2	≈9.2
Density	3.21 g/cm3	3.21 g/cm3
Therm. Expansion Coefficient	4-5×10-6/K	4-5×10-6/K
Refraction Index @750nm	no = 2.61 ne = 2.66	no = 2.60 ne = 2.65
Dielectric Constant	c~9.66	c~9.66
Thermal Conductivity (N-type, 0.02 ohm.cm)	a~4.2 W/cm·K@298K c~3.7 W/cm·K@298K
Thermal Conductivity (Semi-insulating)	a~4.9 W/cm·K@298K c~3.9 W/cm·K@298K	a~4.6 W/cm·K@298K c~3.2 W/cm·K@298K
Band-gap	3.23 eV	3.02 eV
Break-Down Electrical Field	3-5×106V/cm	3-5×106V/cm
Saturation Drift Velocity	2.0×105m/s	2.0×105m/s

Standard specification for sic wafers

4H-N Seed crystal grade 4inch diameter Silicon Carbide (SiC) Substrate Specification

Product show:

CATALOGUE COMMON SIZE

4H-N Type / High Purity SiC wafer/ingots 2 inch 4H N-Type SiC wafer/ingots 3 inch 4H N-Type SiC wafer 4 inch 4H N-Type SiC wafer/ingots 6 inch 4H N-Type SiC wafer/ingots	4H Semi-insulating / High Purity SiC wafer 2 inch 4H Semi-insulating SiC wafer 3 inch 4H Semi-insulating SiC wafer 4 inch 4H Semi-insulating SiC wafer 6 inch 4H Semi-insulating SiC wafer
6H N-Type SiC wafer 2 inch 6H N-Type SiC wafer/ingot	Customzied size for 2-6inch

About ZMKJ Company

ZMKJ can provides high quality single crystal SiC wafer ( Silicon Carbide ) to electronic and optoelectronic industry . SiC wafer is a next generation semiconductor material , with unique electrical properties and excellent thermal properties , compared to silicon wafer and GaAs wafer , SiC wafer is more suitable for high temperature and high power device application . SiC wafer can be supplied in diameter 2-6 inch , both 4H and 6H SiC , N-type , Nitrogen doped , and semi-insulating type available . Please contact us for more product information .

FAQ:

Q: What's the way of shipping and cost?

A:(1) We accept DHL, Fedex, EMS etc.

(2) it is fine If you have your own express account ,If not,we could help you ship them and

Freight is in accordance with the actual settlement.

Q: How to pay?

A: T/T 100％ deposit before delivery.

Q: What's your MOQ?

A: (1) For inventory, the MOQ is 1pcs. if 2-5pcs it's better.

(2) For customized commen products, the MOQ is 10pcs up.

Q: What's the delivery time?

A: (1) For the standard products

For inventory: the delivery is 5 workdays after you place the order.

For customized products: the delivery is 2 -4 weeks after you order contact.

Q: Do you have standard products?

A: Our standard products in stock. as like substrates 4inch 0.35mm.
